The characteristics:
1.Low noise
2.High efficiency
3.It is handy and compact in volume. It saves the space as well.
4.Maintenance-free
5.Firm and durable
6.The products can adapt to the multiple operating conditions. We also offer various brake
motors, the motors with specified voltage, international standard motors and other speci-
fications of the motors
Lnstallation Location:
1. Ambient Temperature: -10℃-40℃
2. Ambient Humidity: 85%max. (without any dew condensation)
3. Altitude: 1,000m max
4. Lnstallation Location : Well ventilated place free from corrosive gas, explosive gas, vapor and/or dust.
Lnstallation Surface:
lnstallation the products with four bolts on a flat and machined surface free from vibration.
Mounting Position:
ALL Products can be mounted in any direction due to a grease lubrication system..
Connecting with other Equipment:
1. "H7" fit is recommended for the hole couplings , sprockets, pulleys, gears etc., when attaching to the
reducer.
2. ln case of direct connection ,connect a reducer shaft and a shaft of the connectingmachine precisely,
so that the center of the shaft of both maceines will be fully aligned.
3. ln cale of using chains, belts gears, etc. connect the units precisely, so that the shaft of the reducer and that of the other machine are parallel. Also, be sure that the centerline of the sprockets and pulleys must be perpendicular to the shaft.
4. When attaching couplings or connecting equipment to the output shaft, be sure not to give any strong
impact by hammer,etc. Failure to observe this warning may cause damage to the bearings, which may lead to noise, vibration or failure
.Cautions for Operation:
1. Load torque, load inertia moment l(GD2), O.H.L. should always be kept within the allowable value in
operation.
2. When reversing the motor, be sure to confirm if the motor is completely stopped. Failure to observe this warning may cause serious damage to rearmotors and the connecting machine by plugging.
3. When reversing a single-phase motor, be sure to start reversing after confirming complete stop of the
motor run out of control in the same direction.
4. Do not stop the motor forcibly. Failuer to observe this warning may cause the motor run out of control
by an unex -pected reversing.
5. Be sure that the temperature of the reducer surface should never cxceed 80 ℃
About Rated Current:
The rated current values listed in the performance table are the area of motor. For gearmotors with brake
and gea-rmotors with clutce/brake, the current through brake coil should also be taken into consideration.
For more details, consult us.
